Module LED Q1.86 Qiangli Pro 320x160mm Indoor
Thông số kỹ thuật module led Q1.86 pro Qiangli 320x160mm trong nhà
| Weight | 0.8 kg |
|---|---|
| Dimensions | 320 × 160 × 15 mm |
| Pixel pitch | 1.86mm |
| LED type | SMD1515 |
| Density | 288,906 pixel/㎡ |
| Module resolution | 172 pixel (L) * 86 pixel (H) |
| Module dimension | 320mm(L) * 160mm(H) * 15mm(D) |
| Driving mode | Constant current, 1/43 duty |
| Brightness | ≥500 cd/㎡ |
| Viewing angle | 120°(Horizontal); 120°(Vertical) |
| Best viewing distance | ≥2m |
| Gray grade | 14 bits |
| Display color | 4.4 trillion colors |
| Brightness adjustment | 100 grades by software or automatically by sensor |
| Max. Power Consumption | 32W |
| Frame frequency | ≥60Hz |
| Refresh frequency | ≥3840Hz |
| Input signal | Composite Video, S-video, DVI, HDMI, SDI, HD-SDI |
| Control distance | 100m (Ethernet cable); 20km (Optical fiber cable) |
| Support VGA mode | 800*600, 1024*768, 1280*1024, 1600*1200 |
| Color temperature | 5000—9300 adjustable |
| Brightness correction | Pixel by pixel, module by module, cabinet by cabinet |
| Working temperature | -20～+60 ºC |
| Storage temperature | -30～+70 ºC |
| Working humidity | 10%～90% RH |
| Lifetime | 100,000 hours |
| MTBF | 5000 hours |
| Continuous operating time | ≥72 hours |
| Protection Grade | IP31 |
| Out-of-Control pixel rate | ≤0.01% |
